IP2312-100 QC 3.0 Type-C Fast Charging Board | 3A Lithium Battery 18650 Charging Module
SKU: IP2312 100 QC 3.0 Type-C
Tk 95
Tk 70
āĻ¸ā§āĻ 25 āĻāĻžāĻāĻž
āĻ¸ā§āĻāĻā§ āĻāĻā§
āĻ¸ā§āĻĒā§āĻ¸āĻŋāĻĢāĻŋāĻā§āĻļāĻ¨:
1-PCS IP2312 QC 3.0 Type-C Fast Charging Board
Specifications:
Chipset: IP2312
Input Interface: Type-C USB port
Input Voltage: 5V (supports QC 3.0 fast charging protocol)
Output Current: Up to 3A
Battery Type: 18650 lithium-ion batteries (single or pack)
Charging Features:
Intelligent fast charging with automatic voltage selection
Constant current/constant voltage charging
Protection Features:
Overcharge protection
Over-discharge protection
Short-circuit protection
Overcurrent protection
Efficiency: >90%
LED Indicators: Charging and fully charged status
Module Size: Approx. 35mm x 20mm x 8mm
Color: Black
Applications:
DIY Power Banks: Create custom high-speed charging power solutions.
Portable Electronics: Reliable charging for gadgets requiring fast charging.
RC Devices & Drones: Efficient battery charging for hobby electronics.
Battery Maintenance: Ideal for recharging and protecting 18650 cells.
Solar Energy Storage: Efficient charging for solar-powered battery packs.
Description:
The IP2312 QC 3.0 Type-C Fast Charging Board is a compact and efficient charging solution for 18650 lithium-ion batteries. Featuring the advanced IP2312 chipset, this module supports QC 3.0 fast charging with input voltages of 5V, 9V, and 12V, providing up to 3A output current for rapid and safe charging.
Integrated safety features such as overcharge, over-discharge, and short-circuit protection ensure the batteryâs longevity and safe operation. LED indicators display charging status, making it easy to monitor progress.
Specifications:
Chipset: IP2312
Input Interface: Type-C USB port
Input Voltage: 5V (supports QC 3.0 fast charging protocol)
Output Current: Up to 3A
Battery Type: 18650 lithium-ion batteries (single or pack)
Charging Features:
Intelligent fast charging with automatic voltage selection
Constant current/constant voltage charging
Protection Features:
Overcharge protection
Over-discharge protection
Short-circuit protection
Overcurrent protection
Efficiency: >90%
LED Indicators: Charging and fully charged status
Module Size: Approx. 35mm x 20mm x 8mm
Color: Black
Applications:
DIY Power Banks: Create custom high-speed charging power solutions.
Portable Electronics: Reliable charging for gadgets requiring fast charging.
RC Devices & Drones: Efficient battery charging for hobby electronics.
Battery Maintenance: Ideal for recharging and protecting 18650 cells.
Solar Energy Storage: Efficient charging for solar-powered battery packs.
Description:
The IP2312 QC 3.0 Type-C Fast Charging Board is a compact and efficient charging solution for 18650 lithium-ion batteries. Featuring the advanced IP2312 chipset, this module supports QC 3.0 fast charging with input voltages of 5V, 9V, and 12V, providing up to 3A output current for rapid and safe charging.
Integrated safety features such as overcharge, over-discharge, and short-circuit protection ensure the batteryâs longevity and safe operation. LED indicators display charging status, making it easy to monitor progress.
